Specialized S-Works Crux 5 SRAM RED XPLR (2027)

$13,999.00
%3Cp%3EEarn%20[points_amount]%20CyclErie%20loyalty%20points%20with%20this%20purchase%3C/p%3E

That's $279.98 toward future purchases!

By Specialized
Color
Size

Pickup available at CyclErie Bikes & Service - Erie, CO

Usually ready in 2-4 days
View details

Specialized S-Works Crux 5 SRAM RED XPLR (2027)

The S-Works Crux 5 is the fastest gravel race bike ever made. Not just because it’s the lightest. Not just because it’s our most aero. Not just because it handles dirt like a Tarmac handles pavement. But because it delivers the lowest real-world Time to Finish of any gravel bike ever made. Crux 5 turns more of your effort into pure speed—validated for real race courses, real terrain, and real riders. When the goal is the top step, nothing in gravel gets you there faster.

Highlights

  • Use - Gravel Racing
  • Frame - FACT 12r Carbon: 789 grams
  • Wheels - Roval Terra Aero CLX
  • Cockpit - Roval Terra Integrated
  • Drivetrain - SRAM RED XPLR
  • Weight - 7.1 kg

Technical Specifications

Frameset

  • Frame: S-Works Crux 5 FACT 12r Carbon, Rider First Engineered™, Threaded BB, 12x142mm thru-axle, flat-mount disc, UDH dropout

Suspension

  • Fork: S-Works FACT Carbon, 12x100mm thru-axle, flat-mount disc

Brakes

  • Front Brake: SRAM RED E1, hydraulic disc
  • Rear Brake: SRAM RED E1, hydraulic disc

Drivetrain

  • Bottom Bracket: Ceramic Speed BB Alpha, BSA DUB
  • Shift Levers: SRAM RED AXS E1, hydraulic disc
  • Rear Derailleur: SRAM RED AXS XPLR E1, 13-speed
  • Chain: SRAM RED E1
  • Cassette: SRAM RED XPLR E1, 13-speed, 10-46t
  • Crankset: SRAM RED XPLR E1, Quarq power meter, 40t

Wheels & Tires

  • Inner Tubes: 700x32-50mm, 60mm Presta valve
  • Front Tire: Pathfinder 700x45, Tubeless Ready
  • Rear Tire: Pathfinder 700x45, Tubeless Ready
  • Front Wheel: Roval Terra Aero CLX, 27mm internal width, tubeless ready, 50mm depth, 18h, Roval LF18-F hub with ceramic SINC bearings, Centerlock disc, Roval by ARRIS, Composite Aero Spoke with Ti End Pieces
  • Rear Wheel: Roval Terra Aero CLX, 27mm internal width, tubeless ready, 45mm depth, 24h, Roval LF19-R hub with ceramic SINC bearings, Centerlock disc, Roval by ARRIS, Composite Aero Spoke with Ti End Pieces

Cockpit

  • Seatpost: S-Works Tarmac SL8 Carbon seat post, FACT Carbon, 15mm offset, Lightweight Saddle Clamp
  • Handlebars: Roval Terra Cockpit, Integrated Bar/Stem
  • Saddle: S-Works Power with Mirror
  • Tape: Supacaz Super Sticky Kush
  • Seat Binder: Integrated Wedge

Geometry (mm)

49 52 54 56 58 61
Stack 530 547 560 578 598 621
Reach 375 382 388 400 412 425
Head Tube Length 95 110 125 142 163 188
Head Tube Angle 70.5 70.75 71 71.5 71.5 71.5
BB Height 278 278 280 280 280 280
BB Drop 80 80 78 78 78 78
Trail 72 71 69 66 66 66
Fork Length, Full 401 401 401 401 401 401
Fork Rake/Offset 51 51 51 51 51 51
Front Center 594 604 613 626 644 665
Chainstay Length 425 425 425 425 425 425
Wheelbase 1008 1016 1026 1039 1057 1078
Top Tube Length, Horizontal 512 534 543 566 583 603
Bike Standover Height 753 766 781 803 823 849
Seat Tube Length 445 456 473 497 515 545
Seat Tube Angle 75.5 74.5 74.5 74 74 74

Weight: 7.1 kg (approx. 15.7 lbs), manufacturer spec
