Overview
Built on a new, very lightweight ALUXX aluminum frame, featuring a classic hardtail design plus the balanced handling characteristics of larger diameter 27.5 or 29-inch wheels. Talon is a great choice for XC or light trail terrain. Its frame geometry is specifically designed to suit its respective wheel size and an 80mm or 100mm suspension (27.5" or 29" rim respectively) gives you a confident ride that's perfect for ambitious riders who want to carry your off-road skills to the next level.
Tech Specs:
- Frame: ALUXX-Grade Aluminum, disc
- Fork: SXC32-2 RL, air spring, QR, alloy steerer XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29) M: 100mm travel (27.5) / 100mm travel (29) L: 100mm travel (27.5) / 100mm travel (29) XL: 100mm travel (29) XXL: 100mm travel (29)
- Bottom Bracket: cartridge
- Stem: Giant Sport, 7-degree XS: 40mm (27.5) S: 50mm (27.5) / 50mm (29) M: 60mm (27.5) / 60mm (29) L: 70mm (27.5) / 70mm (29) XL: 80mm (29) XXL: 90mm (29)
- Handlebar: Giant Connect Trail, 31.8mm XS: 730mm (27.5) S: 780mm (27.5) / 780mm (29) M: 780mm (27.5) / 780mm (29) L: 780mm (27.5) / 780mm (29) XL: 780mm (29) XXL: 780mm (29)
- Saddle: Giant custom
- Seatpost: Giant Sport, 30.9 XS: 300mm (27.5) S: 300mm (27.5) / 375mm (29) M: 375mm (27.5) / 375mm (29) L: 375mm (27.5) / 375mm (29) XL: 375mm (29) XXL: 375mm (29)
- Pedals: MTB caged
- Grips: Giant Sole-O
Groupset:
- Rear Derailleur: Shimano Deore M5120
- Crank: ProWheel Charm, 30t (27.5) or 32t (29) XS: 165mm (27.5) S: 170mm (27.5) / 170mm (29) M: 170mm (27.5) / 175mm (29) L: 175mm (27.5) / 175mm (29) XL: 175mm (29) XXL: 175mm (29)
- Shifters: Shimano Deore M4100, 1x10
- Cassette: Shimano Deore M4100, 11x42
- Chain: KMC X10
- Brakes: Tektro HDC M275, hydraulic, Tektro rotors [F]180mm, [R]160mm
- Brake Levers: Tektro HDC M275
Wheelset:
- Rims: Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width
- Spokes: Stainless, 14g
- Front Hub: alloy, ball bearing
- Rear Hub: alloy, ball bearing
- Tires: Kenda Booster 27.5 or 29x2.4", wire bead
